Elevating Welding Positioner 300Kg 200Kg rotating tilting for pipe
cycliner workpiece
It’s better to learn how the equipment works first if we’re going
to find out how many benefits it can bring us.
The welding positioner, one of the welding auxiliary equipment, was
composed of a work table, a reducer, a slewing bearing, and a drive
device. It helps to make welding easier through position the
work-piece in a suitable position by lifting, rotating and flip.
Brief Introduction:
This shows, the welding positioner can bing us these benefits below
at least:
1. Reduce the worker’s workload and strength: the welding
positioner can drive the work-piece to move. And position the seam
in a proper position for welding. The welding seam will adjust the
positioning according to the worker, not the worker weld in
different poses to suit the welding seam.
2. Improve the welding quality: The welding positioner can clamp
the work-piece and rotate at a preset speed. The only thing that
the worker should do is fix the welding gun in the welding position
to perform complete welding. It can reduce the occurrence of
welding offset because of tiredness.
Applications:
It used in many industries such as pipe, tank, pressure vessel,
boiler, freezing equipment, power station construction,
metallurgical, engineering machinery, marine building, and
petro-chemical industries etc.
Parameter:
| Model | Rated weight bearing (kg) | Rotation speed (rpm) | Speed of table tiling (rpm) | Worktable Tilting angle(°) | Dia. of working table (mm) | Tilting Driving Power (Kw) | Revote Driving Power(Kw) | Speed Adjusting Way | Max gravity center (mm) | Max eccentricity distance (mm) | Equipment Weight(Kg) |
| HB-3 | 300 | 0.2-2 | ≈ 0.9 | 0-120 | Φ600 | 0.37 | 0.37 | VFD | 200 | 150 | 260 |
| HB-6 | 600 | 0.1-1.1 | ≈ 0.8 | 0-120 | Φ800 | 0.55 | 0.37 | 250 | 150 | 700 |
| HB-12 | 1200 | 0.1-1 | ≈ 0.5 | 0-120 | Φ1200 | 1.1 | 0.75 | 250 | 200 | 1000 |
| HB-20 | 2000 | 0.09-0.9 | ≈ 0.4 | 0-120 | Φ1200 | 1.5 | 1.1 | 300 | 250 | 2000 |
| HB-30 | 3000 | 0.08-0.8 | ≈ 0.3 | 0-120 | Φ1400 | 2.2 | 1.5 | 400 | 250 | 3350 |
| HB-50 | 5000 | 0.07-0.7 | ≈ 0.2 | 0-120 | Φ1600 | 3 | 1.5 | 400 | 250 | 4300 |
| HB-80 | 8000 | 0.06-0.6 | ≈ 0.14 | 0-120 | Φ2000 | 4 | 2.2 | 400 | 200 | 8000 |
| HB-100 | 10000 | 0.06-0.6 | ≈ 0.14 | 0-120 | Φ2000 | 4 | 3 | 400 | 200 | 8200 |
Competitive advantage:
1. Main electric elements are Siemens/Schneider.
2. VFD rotary speed control, improving the reliability of
operation.
3. Steel and rubber roller or PU roller which can ensure a long
time using.
4. With lubrication system.
5. Accept testing before delivery.
6. Accept special design and custom.
